| Wavelength | 10600nm+/-100nm |
| Laser Apparatus | Sealed off laser device simulated by direct current |
| Output power | 30w |
| Spot size | 0.02~0.05mm2 |
| Aiming beam | Red semiconductor laser (635nm, less than 5mw) |
| Beam transport device | Articulated arm with 7-joint and balance weight |
| Working mode | Continuous operation |
| Output Mode | Continuous, single pulse, interval pulse and super pulse |
| Scan scope | Less than 20mmx20mm |
| Scan graphics | Circle, triangle, square, rectangle,hexagon, ellipse, line |
| Scanning Mode | Sequence , random and maximum distance s can |
| Scanning speed | More than 10m/s |
| Duration | 1-30w, every 1w is adjustable |
| Pulse interval time | 0~999ms, every 1ms is adjustable |
| Modulation Frequency | 0~999HZ, every 1HZ is adjustable |
| Input power | 450VA |
| Cooling system | Water and air circulation |
| Environment temperature | 5°C~40°C |
| Relative humidity | Less than 80% |
| power | 220V, 50HZ |
